| Data Input |
| SDI Video Input : SD/HD/3G-SDI (BNC 75Ω ) x16 |
| Reference Input : B.B, TRI (BNC 75Ω ) x1 |
| Data Output |
| SDI Video Input : SD/ HD/ 3G-SDI (BNC 75Ω ) x16 |
| Connections |
| Remote Control : RS-422 (RJ45)x1 |
| Ethernet : Ethernet Support (RJ45) x 1 |
| Update : Debug (Micro USB) x 1 |
| Electrical |
| Power Input : 100 ~240 VAC @ 50/60Hz |
| Power Consumption : 18W (max.) |
| Operation Temperature : 0 ~ 40 °C |
| Physical |
| Dimension : 44(H) x 483(W) x 240(D) (mm) |
| Weight : 2.0kg |
