| Parameter | |
| Overview | CG Output through USB 3.0 (Fill&Key) |
| Input | Fill & Key Input : USB 3.0 x 1 |
| Output | Fill & Key Output : SDI x 2 |
| USB Devices | USB 3.0 Video Streamer Device : FIll & KEy Input USB 2.0 USB to Serial (Com Port) Device : Control USB 2.0 USB to SPI Device : Firmware Update |
| System Requirement | OS : Windows10 정품 (64bit) CPU : Intel i5 6세대 이상 GPU : GT x 1050 이상 USB 3.0 Host Controller RAM : 16G |
| Internal Video Processing | YCbCr 4:2:2 10bit |
| Resolution Supported | 1280 x 720p @60/59.94/50 1920 x 1080i @60/59.94/50 |
| Management | USB : Easy to use GUI application, Firmware update |
| Physical | Operation Temperature : 0 - 40 °C Power Consumption : 4W (max.) |
